90MM Throttle Body with Sniper EFI Logo Silver for 2011-present Ford Coyote 5.0L

Sniper EFI's new 90mm billet aluminum throttle bodies are designed as a direct fit for the Fabricated Race intake manifolds. Don't let the low price fool you, these are feature packed throttle bodies available in both bright silver or black anodized finishes. The enlarged bore sizes allow for increased airflow to support your higher horsepower needs, a progressive throttle pulley enhances low speed drivability and a double return spring provides solid and secure throttle control feel.

Features:

  • Cable operated throttle body available in 90mm opening
  • Adjustable throttle stop
  • High quality billet aluminum construction
  • Available in two finishes Silver or Black anodized
  • Laser engraved Sniper EFI logo
  • Progressive throttle pulley and double return spring
  • Mounting bolts included
  • Enlarged bore allows increased airflow to support higher horsepower requirements
  • Designed for us when installing an OEM throttle body for motor housing clearance or can be used as spacer on Sniper EFI intakes for increased horsepower and throttle response

Specs:

Billet Color Silver
Brand Sniper
Category Filter Intake Manifolds
Clearance Category Intake Manifolds
Discount Percentage 26-50%
Emission Code 4
IAC hardware specs (2) 8-32 UNC
Material Billet Aluminum
Product Type Throttle Body
Sale Category Air and Fuel Delivery
Throttle Bore 90mm
Throttle Diameter (mm) 90mm
TPS hardware specs (2) M4 x 0.7
Transmission N/A
Warranty Limited 90 Day
UPC 090127001455
Part Number 860009
SKU 860009
Barcode # 90127001455
Brand Holley Sniper
Shipping Weight 1.2000kg
Shipping Width 0.070m
Shipping Height 0.150m
Shipping Length 0.180m
